RefLED Superia Retro MR16 V2 345LM DIM 827 36 SL
Item No:
0029214
Premium performance professional LED MR16 range with the same look and feel of traditional halogen MR16 lamp Recreates backlight effect similar to halogen dichroic lamps. Full glass design - means no colours clashing between lamp and fixture Very long lifetime of up to 25,000 hours Switching cycles: >100,000 Colour rendering: CRI80 Lamp voltage: 12V AC/DC Dimmable on approved dimmers Works with magnetic and compatible electronic transformers Warranty: 5 Years
Technical Assets
Dimensions (mm)
Photometrics
Product name
RefLED Superia Retro MR16 V2 345LM DIM 827 36 SL
Technology
LED
Watt (Rated) (W)
4.4
Fixture rating
Open
General application
Education, Hospitality, Museums & Galleries, Office, Residential & Consumer, Retail
Operating temperature range (°C)
-20°C...+40°C
Performance ambient temperature Tq (°C)
25
ETIM Class
EC001959
E-number FI
4741094
Warranty
5 years
Useful luminous flux (Φuse)
345
Correlated colour temperature (k)
2700
Light colour
Homelight
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM6
Colour Consistency (SDCM)
6
Luminous Intensity (cd)
800
Beam Angle (°)
36
Photobiological Risk Group
RG1
Lumen maintenance at end of nominal life (%)
70
Power consumption (W)
4.4
Wattage (W)
4.4
Equivalent watt (W)
35
Primary Supply/Product voltage - min (V)
12
Primary Supply/Product voltage - max (V)
12
Control gear required
Yes
No. Of switching cycles before premature failures
>50000
Dimmable
Yes
Inrush Current (A)
6.5
Inrush Duration (µs)
500
Lamp Energy Label (class)
F
Lifespan L70 B50
25000
Average life (Nominal) (h)
25000
Average life (Rated) (h)
25000
Nominal Product Length (mm)
44
Nominal Product Diameter (mm)
50
Weight (kg)
0.03
Product EAN number
5410288292144
Packaging single length / height (cm)
6.1
Packaging single width (cm)
5.1
Packaging single depth (cm)
8.2
DUN14 (inner)
15410288292141
Units per inner package
6
Packaging inner length / height (cm)
16.4
Packaging inner width (cm)
13.2
Packaging inner depth (cm)
9.3
DUN14 (outer)
25410288292148
Units per outer package
48
Packaging outer length / height (cm)
34.6
Packaging outer width (cm)
28.2
Packaging outer depth (cm)
20.8
Optimal operating condition (°C)
-20-40
Breakage cleaning instructions
Not applicable
Special purpose lamp
No
Dry applications use only
Yes
Suitable for household illumination
Yes
Safety message
Suitable for approved transf./dimmers
